The Infrared Tunnel Oven is a continuous heating system that uses infrared radiation as the primary heating method. It is designed for fast surface heating and efficient drying or curing processes. With multi-zone temperature control and integrated cooling sections, the equipment supports stable and continuous production, especially for precision industrial applications.
The Infrared Tunnel Oven is widely used in:
(1) Automotive parts drying and curing.
(2) Electronic and semiconductor processing.
(3) Optoelectronic product manufacturing.
(4) New energy material processing.
(5) Glass and precision hardware treatment.
(6) Silicone and medical device production.
The equipment can comply with:
(1) GB/T 10067 Industrial Heating Equipment Technical Requirements
(2) GB 5226 Electrical Safety of Machinery
(3) General industrial oven and safety standards
| Item | Specification |
|---|---|
| Equipment Type | Infrared Tunnel Oven |
| Heating Section Size | L5000 × W1370 × H1300 mm |
| Heating Zone Length | 4500 mm |
| Inner Chamber Size | L4500 × W970 × H440 mm |
| Cooling Section Size | L5000 × W1370 × H1130 mm |
| Cooling Zone Length | 7200 mm |
| Loading/Unloading Length | 500 mm each |
| Transition Section | 300 mm |
| Fixture Size | 180 × 180 mm |
| Temperature Zones | 3 independent zones |
| Temperature Range | Room temperature ~ 250℃ |
| Working Temperature | Approx. 200℃ |
| Temperature Uniformity | ±5℃ |
| Temperature Accuracy | ±1℃ |
| Heating Rate | ≥5℃/min |
| Air Circulation | Horizontal forced air circulation |
| Heating Method | Infrared heating tubes |
| Heating Power | Approx. 20KW |
| Total Power | Approx. 30KW |
| Power Supply | 380V, 50Hz, three-phase five-wire |
(1) Infrared heating provides fast response and efficient heating.
(2) Multi-zone control supports flexible process settings.
(3) Integrated cooling section improves production efficiency.
(4) Suitable for precision and sensitive materials.
(5) Continuous conveyor design for stable operation.
(6) Easy to customize for different production needs.
(1) What are the advantages of an Infrared Tunnel Oven?
It provides fast heating speed and efficient energy transfer, especially suitable for surface heating and drying processes where quick response is required.
(2) What industries can use this equipment?
It is widely used in automotive, electronics, semiconductor, glass, medical, and new energy industries for drying and curing applications.
(3) Is it suitable for continuous production lines?
Yes. The conveyor-based design allows continuous processing and easy integration into automated production systems.
(4) How does it improve production efficiency?
By combining rapid infrared heating with a cooling section, the system shortens processing time and supports faster production cycles.
(5) Can the Infrared Tunnel Oven be customized?
Yes. The structure, size, heating zones, and configuration can be customized according to specific product and process requirements.
