Carpet Pile Height Gauge
StandardASTM D1335 (Standard Test Method for Pile Thickness of Finished Wool Textile Floor Coverings
Email: info@standard-groups.com
Content
Standard
- ASTM D1335 (Standard Test Method for Pile Thickness of Finished Wool Textile Floor Coverings)
- ISO 1765 (Textile Floor Coverings - Determination of Pile Thickness)
- EN 428 (Resistance to Pile Compression for Carpets)
Product Advantages
- Unmatched Precision
- Laser-guided sensor (±0.01mm accuracy) captures even subtle variations in pile height, essential for luxury wool, shag, and high-pile carpets.
- Non-Destructive Testing
- Patented contactless measurement technology preserves sample integrity, allowing repeated testing on the same carpet.
- User-Centric Design
- 4.3-inch HD touchscreen with multilingual support (English, French, Arabic, Japanese) and one-touch calibration for effortless operation.
- Portable & Rugged
- Compact aluminum alloy body withstands drops and vibrations, ideal for factory-floor and field use.
- Cost-Efficient Operation
- Rechargeable lithium battery provides 24 hours of continuous testing, eliminating the need for disposable power sources.
Product Features
- Multi-Mode Measurement:
- Spot Measurement: Precision analysis of specific areas (e.g., worn patches, seam transitions).
- Scan Mode: Continuous 50mm traverse for mapping pile height variations across carpet widths.
- Data Management:
- Onboard memory stores 5,000+ measurements, exportable via USB/Bluetooth in CSV/PDF formats. Compatible with QC software platforms.
- Adjustable Pressure:
- Selectable measurement force (0.5–2 N) to simulate foot traffic or furniture weight impact.
- Universal Compatibility:
- Accommodates carpets up to 50mm pile height, including loop pile, cut pile, and multilevel designs.
Technical Parameters
| Parameter | Specification |
|---|
| Measurement Range | 0–50mm (±0.01mm accuracy) |
| Resolution | 0.001mm |
| Measurement Force | 0.5–2 N (adjustable) |
| Scan Mode Speed | 10–100 mm/s (adjustable) |
| Battery Life | 24 hours (rechargeable) |
| Dimensions (L×W×H) | 180×80×40 mm |
| Weight | 0.5 kg |
| Operating Environment | 0–40°C, ≤85% RH (non-condensing) |
Accessories Included
- Calibration Plate: NIST-traceable reference block for annual validation.
- Carrying Case: Rugged IP67-rated case with foam inserts for safe transport.
- USB Charging Cable: Fast-charge adapter for global power compatibility.
- User Manual & Software: Digital guide (multilingual) + PC software for 3D pile height mapping and ISO-compliant reporting.
- Cleaning Kit: Microfiber cloth and compressed air duster for sensor maintenance.
Ideal For:
- Carpet manufacturers (luxury, commercial, residential)
- Flooring retailers verifying product specifications
- Quality control laboratories
- Architectural firms specifying custom carpets
