Touch Screen Oven

The Touch Screen Oven is a high-end kitchen appliance that combines modern intelligent touch control

WhatsApp : +86 15601902607

Email : info@qinsun-lab.com

Content

The Touch Screen Oven is a high-end kitchen appliance that combines modern intelligent touch control technology with traditional baking processes. It replaces traditional mechanical knobs with a color or high-definition touch screen as the main control interface. Equipped with an intelligent operating system, it supports multi-stage programmable baking, cloud recipe downloads, and precise temperature control, making cooking more intuitive, convenient, and technologically advanced.

Product Applications

Daily Baking:

Easily prepares bread, cakes, cookies, and various Western and Chinese-style pastries.

Meat Roasting:

Perfectly suitable for roasting whole chicken, steaks, lamb chops, and seafood dishes.

Dough Fermentation:

Provides a stable constant-temperature environment for dough fermentation or yogurt making.

Dehydration and Drying:

Used for making homemade pet treats, dried fruits, dried vegetables, and herbal tea ingredients.

Food Reheating:

Can replace a microwave oven for reheating and defrosting leftover food.

Technical Parameters

ParameterSpecification
Overall Dimensions (W×D×H)W1400 × D3600 × H1770 mm
Inner Chamber Dimensions (W×D×H)W1000 × D3450 × H1000 mm
Temperature RangeRoom temperature to 250℃ (Adjustable)
Power8 kW
Power SupplyThree-phase five-wire system, 380V, 50Hz
Temperature Uniformity±3℃ (No-load test)
Air Circulation MethodHot air horizontal circulation
Heating MethodTaiwan-made stainless steel heating tubes
Thermal Insulation100 mm thick high-temperature resistant aluminum silicate fiber cotton insulation; high-temperature resistant silicone sealing strips added around the door edges
External MaterialThe outer shell is made of 2.0 mm cold-rolled steel sheet with high-temperature powder coating surface treatment
Inner Chamber MaterialMade of 1.5 mm thick 304 stainless steel sheet
Protection FunctionsPID self-tuning, automatic constant temperature control, automatic timing (equipped with a high-precision digital automatic timer adjustable up to 999 minutes/hours), over-temperature power-off alarm after reaching the set temperature, over-temperature power cut-off, emergency stop switch, leakage protection circuit breaker, motor overload protection, and other safety functions

Product Features

Simple Touch Control:

The clear and intuitive interface allows one-touch sliding adjustment of time and temperature, completely eliminating complicated mechanical knobs.

Smart Recipes:

Built-in multiple one-touch cooking menus automatically select the optimal temperature control curve, allowing beginners to achieve excellent cooking results easily.

Precise Temperature Control:

Equipped with a microcomputer NTC dual temperature sensing probe, which monitors temperature differences inside the chamber in real time to ensure even coloring and consistent cooking results.

Multi-function Integration:

Combines the functions of an oven, air fryer, fermentation machine, dehydrator, and defrosting cabinet in one appliance.

Easy Cleaning:

The full-screen tempered glass panel and enamel inner chamber provide high-temperature resistance, scratch resistance, and oil resistance, allowing easy cleaning with a simple wipe.

FAQ

Q1: Will oil stains or wet hands affect the touch screen sensitivity?

A1:No. The screen uses an industrial-grade capacitive touch system with a waterproof and oil-resistant coating, ensuring accurate operation even with wet hands or slight oil contamination.

Q2: Will the surface of the touch screen become hot during oven operation?

A2:No. The oven door and control panel use multi-layer insulated glass and an efficient heat dissipation system, keeping the screen surface at a safe temperature during operation.

Q3: Can the built-in smart recipes be modified or added?

A3:Yes. Users can adjust the time and temperature settings of preset recipes, and can also connect the oven to a mobile APP via Wi-Fi to customize and save personal recipes.

Q4: If the capacitive touch screen fails, can the oven still operate normally?

A4:No. The touch screen is the core control module of the oven. However, the screen components undergo strict high-temperature resistance and service life testing, making failures extremely rare under normal use.

Q5: What is the difference between the enamel inner chamber and a conventional aluminum-plated inner chamber?

A5:The enamel inner chamber provides better heat retention and energy efficiency. It is also more resistant to oil stains and scratches, offering a longer service life and easier cleaning compared with ordinary aluminum-plated inner chambers.
