Performance: (for no-load, the air-cooled at room temperature 25 ℃)
| Temperature range | -40 ℃ ~ 150 ℃ |
| Temperature Control Stability | ± 0.2 ℃ |
| Temperature distribution is | ± 1.0 ℃ (above 80 ℃ and below -40 ℃ the temperature distribution is ± 1.5 ℃) |
| Temperature rise time | room temperature rise to 150 ℃ need 35 minutes |
| Cooling time | |
| Temp range Time needed | 20~ 0℃ About 30 minutes 20~-20℃ About 40 minutes 20~-40℃ Around 50 minutes |
| Humidity | 10% ~ 98% RH. Note: 10% at 60 degrees when the temperature and humidity control can be |
| Stability | ± 2.5% RH |
| Humidity distributions are degrees | ± 3% |
| Temperature and humidity control | (ordinary normal range) |
Controller: Use the high precision microcomputer touch temperature and humidity controller with high stability of platinum resistance to temperature and wind speed in the circulatory system of temperature and humidity test.
View window: A large transparent glass window to observe the testing samples.
Material: (inner chamber materialz) SUS#304 stainless steel plate; (exterior chamber material) stainless steel plate
Insulation: Double-insulated airtight container
Compressor:imported French " Tecumseh "
Humidifier dry-combustion protection
Independent over-temperature protection
Water shortage protection
Over-current protection
Refrigerant high-pressure protection switch
Over-current circuit breaker
Earth leakage protection and so on.
