Features and Benefits1. Radius of oscillating tube: 400mm/600mm/800mm2. Water pipe diameter: 18
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Radius of oscillating tube: 400mm/600mm/800mm
2. Water pipe diameter: 18mm Nozzle diameter: 0.4mm or 0.8mm Optional water spray pressure: 50～100kpa
3. There is a water tank at the bottom of the test chamber, a test water spray system, a worktable rotation system, and a swing tube swing drive device
4. Sealing: Double-layer high-temperature resistant and high-tensile sealing strips are used between the door and the chamber to ensure the tightness of the test room.
Model | R-800C | R-1200C |
Internal Dimensions (mm) | 900*950*950 | 1300*1350*1370 |
Overall Dimensions (mm) | 1180*1420*1920 | 1540*1820*2200 |
Useful Volume (L) | 810 | 2400 |
Oscillating Tube Radius | 400mm | 600mm |
Spraying Hole Diameter | φ0.4mm | |
Hole Spacing | 50 mm | |
Swing Angle of Oscillating Tube | 0 ~ ±180° (Adjustable） | |
Turntable Rotation Speed | 1r/min (Adjustable speed) | |
Water Pressure Control | Flow meter | |
Controller | Programmable color LCD touch screen controller, Ethernet connection | |
Water supply system | Water tank, booster pump, Automatic water supply, Water purification system | |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection | |
Exterior Material | Steel Plate with protective coating | |
Interior Material | SUS304 stainless steel | |
Observation Window | Double layer insulating glass with wiper | |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
