Features and Benefits 1. The material of the working room is SUS304 stainless steel, all welded
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. The material of the working room is SUS304 stainless steel, all welded surfaces and cross-sectional surfaces have been pickled to prevent rust.
2. The drip tray is placed above the workroom to achieve IPX1 X2 drip test.
3. The oscillating tube can swing from 0 to 180° to achieve IPX3 X4 test.
4. Our main rain chambers include dripping water test chamber, spraying water test chamber, water jets test chamber and high temperature and high pressure water test chamber.
5. Build a new IP laboratory for you according to your requirements.
Model | R-800 | R-1200 | |
Internal Dimensions (mm) | 900*900*900 | 1400*1400*1400 | |
Overall Dimensions (mm) | 1180*1420*1920 | 1540*1820*2200 | |
Interior Volume (L) | 720 | 2740 | |
Parameter | Spraying Hole Diameter | φ0.4mm | |
Hole Spacing | 50 mm | ||
Swing Angle of Oscillating Tube | 0 ~ ±180° (Adjustable） | ||
Turntable Rotation Speed | 1r/min (Adjustable) | ||
Oscillating Tube Radius | 400mm | 600mm | |
Standard | IEC 60529, ISO20653 | ||
