Key Features 1. Multi-scene waterproof test capability,IPX1-2 vertical/inclined dripping,IPX3-4
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Multi-scene waterproof test capability,IPX1-2 vertical/inclined dripping,IPX3-4 dripping/splashing
2. High precision flow meter automatically adjusts the water volume to meet the flow requirements of different levels of IPX1-4.
3. Safety protection: leakage protection switch, emergency stop button, water shortage alarm to ensure the safety of operators.
4. Water circulation system, built-in filter device, to achieve water recycling, reduce waste.
5. The main body and key components (such as nozzles and pendulum tubes) are made of SUS304 stainless steel, which can withstand humid environment for a long time.
6. Rotating turntable (adjustable speed) with waterproof power supply, water can be evenly sprayed on the surface of the test
Model | R-800C | R-1200C |
Internal Dimensions (mm) | 900*950*950 | 1300*1350*1370 |
Overall Dimensions (mm) | 1180*1420*1920 | 1540*1820*2200 |
Useful Volume (L) | 810 | 2400 |
Oscillating Tube Radius | 400mm | 600mm |
Drip Tray Size | 600*600 | 1000*1000 |
Spraying Hole Diameter | φ0.4mm | |
Hole Spacing | 50 mm | |
Swing angle of Oscillating Tube | 0 ~ ±180° (Adjustable） | |
Turntable Rotation Speed | 1r/min (Adjustable speed) | |
Water Pressure Control | Flow meter | |
Controller | Programmable color LCD touch screen controller, Ethernet connection | |
Water supply system | Water tank, booster pump, Automatic water supply, Water purification system | |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection | |
Exterior Material | Steel Plate with protective coating | |
Interior Material | SUS304 stainless steel | |
Observation Window | Double layer insulating glass with wiper | |
