Features and Benefits 1. SUS304 stainless steel, water resist corrosion and high temperature.2.
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. SUS304 stainless steel, water resist corrosion and high temperature.
2. Automatic switching of nozzle angle and time, reducing manual intervention, only 2 minutes per test.
3. Stepper motor drive, turntable speed 5±1 r/min, to ensure uniform sample testing.
4. Comply with IEC 60529, ISO 20653, DIN 40050-9 and other international standards, authoritative test results.
5. Large area observation window with wiper, easy to view DUT test status in real time.
6. The water circulation system reduces water consumption with large capacity water tank, supporting long-term continuous testing.
7. Real-time display of pressure, temperature, flow, support data export and printing.
Model | R9K-1200 |
Internal Dimensions (mm) | 1000*1200*1000 |
Overall Dimensions (mm) | 1250*1700*2050 |
Interior Volume (L) | 1200 |
Water Spray Angle | 0°, 30°, 60°, 90° |
Water Spray Temperature | Ambient ~ +88℃ (Adjustable) |
Spray Nozzle | Four, 30 Seconds each position |
Distance from Water Spraying to Specimens | 10~15cm |
Water Pressure | 8000-10000 Kpa (Adjustable) |
Water Flow Rate | 14L-16L/min |
Testing Platform Speed | 5±1 r.p.m |
Testing Platform Height | 200-400 nm (Adjustable) |
Testing Platform Diameters | 600mm |
Heater Elements | Nichrome heater |
Controller | Programmable color LCD touch screen controller, Ethernet connection |
Door Lock | Electromagnetic lock |
Water supply system | Storage water tank; Booster pump; Automatic water supply; Water purification system; |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth Leakage Protection; Phase Sequence Protection |
Exterior Material | Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
Observation Window | Double layer insulating glass with wiper |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
