1. One can realize two kinds of waterproof level test, IPX5 Shower can carry out IPX5 IPX6 test, equipped with two kinds of nozzles.
2. IPX5 Shower can imitate low-pressure jet water, water intrusion in daily life such as faucet spray, moderate rain and other scenes, and can also simulate strong jet water, such as heavy rain, big waves and other harsh strong water environment.
3. The use of durable material, the external is 4mm A3 steel plate, the internal material is SUS304, which ensures that the structure is stable and not easy to damage under long-term use and water impact.
4. Standardized and customized IPX5 Shower according to your needs for you to choose, all test chambers can pass CE,CSA,UL,RHOS certification.
Model | R56-800 | |
Workroom dimension (mm) | 800*800*800 D*W*H | |
External dimension (mm) | 950*3150*1800 D*W*H | |
Interior Volume (L) | 510 | |
Diameter of Turntable (mm) | 600 | |
Turntable loads | 20kgs Max | |
Parameter | Turntable Rotation Speed | 0~7r/min (Adjustable) |
Internal Diameter of IPX5 Nozzle | 6.3mm | |
Internal Diameter of IPX6 Nozzle | 12.5mm | |
Water Flow Rate IPX5/ IPX6 | 12.5L/min ±5% / 100L/min ±5% | |
Build-in Water Tank(mm) | 370*375*950 | |
Environmental Conditional | 5℃～+35 ℃ ≤85% RH | |
Standard | IEC 60529, ISO20653 | |
