Haze meter

Standard

The Haze Meter STDYH40 adheres to global standards including ASTM D1003/1044, ISO 13468/14782, JIS K7105, and GB/T 2410, ensuring compliance with rigorous quality control protocols. Designed for transmittance (0–100%) and haze (ASTM/ISO) measurements, it meets the demands of industries such as glass processing, automotive coatings, pharmaceutical packaging, and display manufacturing. Certified for CIE D65, A, and C illuminants, it guarantees consistent results across lighting conditions.

Product Advantages

1. Multi-Angle Flexibility
   • Open measurement zone supports vertical and horizontal testing, accommodating samples of varying sizes and shapes.
2. Simplified Calibration
   • Single-step 100% calibration reduces setup time, enabling immediate operation.
3. Versatile Aperture Options
   • Four interchangeable apertures (Φ20mm/Φ15mm/Φ8mm/Φ4mm) adapt to diverse testing requirements, from films to thick glass.
4. Unmatched Precision
   • 0.01 resolution and ≤0.02 repeatability ensure reliable data for critical QC decisions.
5. Portable & Ergonomic
   • Compact 1.3kg design with anti-slip grip and 238mm height for comfortable handling in labs or production lines.
6. Intuitive User Interface
   • 3.5" TFT capacitive touchscreen auto-rotates based on device orientation, minimizing operator fatigue.
7. Dual Measurement Modes
   • Switch between single-shot and average (2–99 scans) modes for customized workflows.
8. Full-Spectrum LED Illumination
   • 400–700nm LED array meets CIE D65, A, and C standards for accurate haze/transmittance analysis.
9. Dual-Standard Compliance
   • Supports ASTM and ISO methodologies, bridging international quality requirements.
10. Advanced Data Management
    • Includes HQC Software for generating professional reports, tracking trends, and exporting data in multiple formats.

Product Features

• Optical System: 0/D geometry with 90mm integrating sphere for diffuse light capture.
• Sensor: PD array detector with CIE V(λ) 2° visual response for human-eye-matched results.
• Measurement Range: 0–100% transmittance with 0.01% resolution.
• Haze Metrics: ASTM D1003/ISO 13468-compliant haze calculation for transparent/semi-transparent materials.
• Sample Handling: Accepts samples up to 40mm thick (e.g., laminated glass, injection-molded plastics).
• Connectivity: USB and Bluetooth for real-time data transfer to PCs/tablets.
• Power: 5000mAh lithium battery with 8-hour runtime (5000+ scans).
• Durability: LED light source rated for 3M+ measurements (5+ years).
• Display: Pass/Fail indicator for instant QC verification.
• Environmental Resistance: Operates in 0–40°C (32–104°F) conditions.

Technical Parameters

Accessories

• Haze Meter STDYH40 Unit
• Power Adapter & USB Cable
• 4x Interchangeable Apertures (Φ20/15/8/4mm)
• HQC Quality Control Software (Downloadable)
• User Manual & Calibration Certificate
•  Micro-Printer, Test Fixtures, Certified Haze Standards
