Features and Benefits1. Wide temperature range can meet the testing requirements of various pro
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Wide temperature range can meet the testing requirements of various products for high and low temperature limit conditions.
2. The high and low temperature impact test chamber is made of high quality sealing materials and insulation materials, preventing heat loss and interference.
3. The specimen does not need to be moved. It is very easy to place the test specimens and suitable for large objects.
4. In addition to hot and cold air impact, the high and low temperature impact test chamber can also be customized air to liquid impact, liquid to liquid impact, etc.
Model | STD 3TS-100 | STD 3TS-210 | STD 3TS-300 | STD 3TS-500 | |
Internal Dimensions (mm) | 500*500*400 | 700*600*500 | 700*780*550 | 900*800*700 | |
Overall Dimension (mm) | 1150*1950*2100 | 1350*2100*2200 | 1350*2250*2300 | 2500*2250*2150 | |
Interior Volume (mm) | 100L | 210L | 300L | 500L | |
Loading Capacity | 10kg | 15kg | 25kg | 35kg | |
Pre-heat Room | Upper limit Temperature | +220℃ | |||
Heating Time | Ambient ~ + 200℃, within 30 minutes | ||||
Pre-cool Room | Lower limit Temperature | -75℃ | |||
Cooling time | Ambient ~ -70℃, within 30 minutes | ||||
Test Room | High Temperature Exposure Range | Ambient +20 ~ +200°C | |||
Low temperature Exposure Range | –65 ~ -5°C | ||||
Temperature Fluctuation | ≤±0.5℃ | ||||
Temperature Deviation | ≤±3 ℃ | ||||
Temperature Recovery Time | Within 5 minutes | ||||
Cooling System | Mechanical compression refrigeration system | ||||
Controller | Programmable color LCD touch screen controller, Ethernet connection | ||||
Safety Device | Over-temperature protection, Over-current protection; Refrigerant high-pressure protection; Earth leakage protection | ||||
Exterior Material | Steel Plate with protective coating | ||||
Interior Material | SUS304 stainless steel | ||||
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | ||||
Standard Configuration | 2 shelves | ||||
Disclaimer: The above content is for reference and communication only among industry insiders, and does not guarantee its accuracy or completeness. According to relevant laws and regulations and the regulations of this website, units or individuals who purchase related items should obtain valid qualifications and qualification conditions.
