Features and Benefits1. Accurate Climate ControlProvides precise and stable temperature (±0.5°C
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Accurate Climate Control
Provides precise and stable temperature (±0.5°C) and humidity (±2%RH) conditions for long-term testing.
2. Uniform Temperature and Humidity Distribution
Advanced air circulation ensures consistent conditions throughout the chamber.
3. Customizable Testing Conditions
Adjustable parameters such as temperature and humidity allow simulation of various storage and transport environments.
4. Energy-Efficient Design
Optimized thermal insulation and humidity regulation help reduce power consumption during continuous operation.
Model | STD TH-100 | STD TH-225 | STD TH-500 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Controller | Programmable color LCD touch screen controller,PC Link, LAN interface for remote control | |||
Cooling system | Mechanical compression refrigeration system | |||
Refrigerant | Environmentally friendly refrigerant | |||
Water supply system | Automatic water supply; Water purification system | |||
Safety device
| Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | |||
Interior Material | SUS304 stainless steel | |||
Exterior Material | Steel Plate with protective coating | |||
