Features and Benefits1. Wide Temperature Range：Selectable from -20°C, -40°C, -60°C, or -70°C up
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Wide Temperature Range：Selectable from -20°C, -40°C, -60°C, or -70°C up to +150°C, with a high-efficiency nickel-chromium heater for fast and accurate control.
2. Flexible Humidity Control：Humidity range of 10%–98%RH or 20%–98%RH, using a stainless steel surface evaporation humidifier with external isolation for stable performance.
3. Multi-Environmental Compatibility：Compatible with vibration, low pressure, and other systems for combined testing to simulate real-world conditions.
4. Standard and Custom Models：Offers both standard designs and fast-delivery customized solutions to meet specific testing needs.
5. On-Site Installation and Training: LIB engineers provide setup and training. User-friendly interface makes operation simple and efficient.
Model | STD TH-100 | STD TH-225 | STD TH-500 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Controller | Programmable color LCD touch screen controller,PC Link, LAN interface for remote control | |||
Cooling system | Mechanical compression refrigeration system | |||
Refrigerant | Environmentally friendly refrigerant | |||
Water supply system | Automatic water supply; Water purification system | |||
Safety device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | |||
Interior Material | SUS304 stainless steel | |||
Exterior Material | Steel Plate with protective coating | |||
Disclaimer: The above content is for reference and communication only among industry insiders, and does not guarantee its accuracy or completeness. According to relevant laws and regulations and the regulations of this website, units or individuals who purchase related items should obtain valid qualifications and qualification conditions.
