1. Wide Humidity & Temperature Range
Offers precise control over humidity from 20% to 98% RH and temperature from -70°C to +150°C, simulating real-world environmental extremes with accuracy.
2. Stable and Uniform Control
Utilizes advanced PID controllers and balanced temperature-humidity control (BTHC) systems to ensure consistent environmental conditions across the test space.
3. Anti-Corrosion & Durable Design
Interior is made of SUS304 stainless steel with mirror finish, highly resistant to corrosion and suitable for long-term, high-humidity operation.
4. Customizable Configurations
Chambers can be tailored in size, door style, port locations, or humidity response speed to meet non-standard test specifications.
5. Compliance with International Standards
Fully compliant with IEC, MIL, ASTM, and ISO humidity test standards, ensuring global acceptance of test results.
Model | STD TH-100 | STD TH-225 | STD TH-500 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Controller | Programmable color LCD touch screen controller,PC Link, LAN interface for remote control | |||
Cooling system | Mechanical compression refrigeration system | |||
Refrigerant | Environmentally friendly refrigerant | |||
Water supply system | Automatic water supply; Water purification system | |||
Safety device
| Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | |||
Interior Material | SUS304 stainless steel | |||
Exterior Material | Steel Plate with protective coating | |||
