Features and Benefits1. Adopts high-intensity xenon lamps with a spectral range of 300-400 nm,
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Adopts high-intensity xenon lamps with a spectral range of 300-400 nm, which can accurately simulate ultraviolet rays, visible light and infrared rays in natural sunlight, providing a realistic testing environment.
2. With an acceleration factor of 5 to 10 times, significantly shortens the testing time through strong light exposure, thereby quickly evaluating the performance of materials when exposed to sunlight and the environment for a long time
3. The temperature range is from RT to 100°C, and the humidity range is from 50% to 98% RH. It can simulate various climatic conditions and comprehensively assess the weather resistance of materials.
4. Test 42 samples simultaneously. The standard sample size is 95mm x 200mm, which improves the testing efficiency and meets the demand for a large number of samples
Model | STD XL-S-750 |
Internal Dimension (mm) | 950*950*850 mm |
Overall Dimension (mm) | 1400*1400*1950 mm |
Specimen Holder Size(mm) | 95*200 |
Specimen Capacity | 42pcs |
Chamber Type | Rotating Holder |
Irradiation Source | 1 piece of 4500w water-cooled xenon arc lamp |
Irradiance Range | 35~150 W/㎡ |
Bandwidth Measurement | 300nm~400nm (340nm or 420nm) |
Chamber Temperature Range | Ambient ~ 100 ℃ ±2℃ |
Black Panel Temperature | BPT 35 ~ 85 ℃ ±2℃ |
Humidity Range | 50% ~ 98% RH |
Humidity Deviation | ± 5% RH |
Water Spray Cycle | 1~9999H59M (Adjustable) |
Controller | Programmable color LCD touch screen controller |
Water supply system | Automatic water supply, Water purification system |
Radiometer | UV Radiometer, Tolerance: ±5% |
Cooling System | Mechanical compression refrigeration system |
