Features and Benefits1. The UVA aging machine can focus on the simulation of the long wave ultr
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. The UVA aging machine can focus on the simulation of the long wave ultraviolet (UVA) band (315-400nm), which accounts for a relatively large proportion of sunlight's ultraviolet rays and has strong penetration.
2. Through the combination of enhanced UVA irradiation intensity and extreme environmental conditions (high temperature, rain), the aging process of the material in the natural environment for months or even years can be simulated in a relatively short time.
3. Equipped with water circulation system, automatic water intake and automatic filtration to ensure the smooth work of the spray system, save water resources.
4. Flexible and versatile sample holder customization to meet standard flat plate and complex 3D samples.
Model | UV-SI-260 |
Internal Dimension (mm) | 450*1170*500 |
Overall Dimension (mm) | 610*1330*1470 |
Specimen Holder Size(mm) | 75*150 |
Specimen Capacity | 56 Pieces |
Irradiation Source | Fluorescent UV lamps (8) - 40 W |
Temperature Range | Ambient ～ 90 ℃ ±2℃ |
Black Panel Temperature (BPT) | 35 ～ 80 ℃ |
Humidity Range | ≥95% RH |
Bandwidth | 290 ~ 400nm |
Irradiance Control | 0.3~20 W/㎡ |
Water Spray Cycle | 1~9999H59M (Adjustable) |
Distance of Specimen and lamp | 50mm |
Controller | Programmable color LCD touch screen controller, Ethernet connection |
Water Supply System | Automatic water supply, Water purification system |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
Exterior Material | Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
