Standard
Engineered to comply with global testing standards (ISO 3953, ASTM B527), our Powder Tapped Density Analyzer provides certified results for quality control in pharmaceuticals, batteries, ceramics, and additive manufacturing. Meets CE/UL safety certifications for laboratory equipment.
Product Advantages
- Unparalleled Precision
- Dynamic Tapping Mechanism: Programmable tapping cycles (1–3000 taps) with adjustable amplitude (1–50 mm) to simulate industrial compaction processes.
- High-Resolution Sensing: Laser-based volume detection (±0.01 cm³ accuracy) captures subtle density changes in micro-powders.
- Automated Workflow
- One-Touch Operation: Preset protocols for pharmaceutical USP methods or custom tapping sequences. Automatically calculate Hausner Ratio and Carr Index.
- Real-Time Curve Generation: Plot density vs. tap count, pressure, and environmental conditions (temperature/humidity) during testing.
- Material Versatility
- Optimized for:
- Battery electrodes (Li-ion, Na-ion, solid-state)
- Pharmaceutical excipients and APIs
- 3D printing powders (metal, ceramic, polymer)
- Abrasives, catalysts, and food additives
- Data Integrity
- 21 CFR Part 11-compliant software with audit trails, electronic signatures, and encrypted data storage. Export reports in PDF/Excel formats.
- Calibration Assurance
- Pre-installed NIST-traceable density standards (1 g/cm³, 2.5 g/cm³) for instant verification.
Product Features
- Pressure Control: Closed-loop hydraulic system applies up to 500 MPa with ±0.1% FS stability.
- Environmental Monitoring: Integrated sensors for temperature (-10°C to 80°C) and humidity (5–95% RH) with automatic drift correction.
- Modular Design: Swapable testing cells (1–500 cm³) for R&D to production-scale samples.
- Safety: Overpressure protection, emergency stop, and HEPA-filtered dust containment.
- Connectivity: Wi-Fi/Bluetooth for remote monitoring, compatible with LIMS systems.
Technical Parameters
| Parameter | Specification |
|---|
| Tapping Range | 1–3000 taps (adjustable speed: 10–60 taps/min) |
| Density Measurement | 0.1–5.0 g/cm³ (±0.005 g/cm³ accuracy) |
| Pressure Application | 0–370 MPa (programmable ramp rates) |
| Temperature Control | -10°C to 80°C (±0.2°C stability) |
| Humidity Tolerance | 5–95% RH (non-condensing) |
| Display/Interface | 10.1" touchscreen with multi-language GUI |
| Power Consumption | 600 W (110–240 V AC, 50/60 Hz) |
| Dimensions (W×D×H) | 500 × 600 × 800 mm |
Accessories Included
- Main Unit: Powder Tapped Density Analyzer with safety enclosure.
- Software Package: Compliance-ready SPC software with FDA 21 CFR Part 11 modules.
- Testing Kits:
- Set of 3 stainless-steel density cells (10 cm³, 50 cm³, 250 cm³).
- Calibration weights (100 g, 500 g) with certificate.
- Dust Management: HEPA filter unit and anti-static brush.
- User Documentation: Multilingual quick-start guide and maintenance manual.
