1. STD IP6X is the highest level of dust protection standard, representing complete prevention of dust from entering the equipment. In full compliance with IEC 60529 IP6X standard.Adjustable range of test time: 1 min to 9999 min.
2. The interior is equipped with high-precision sensors and a closed-loop control system, which can precisely monitor and adjust the wind speed, pressure difference and dust concentration inside the workroom.
3. The large-volume workroom and high-efficiency circulation system can accommodate various test samples, support batch testing, and improve experimental efficiency.
4. Key components such as fans, sensors, and sand and dust distributors all adopt modular design, facilitating rapid replacement and maintenance.Multiple safety protection measures at the same time.
Model | DI-800 | DI-1000 | DI-1500 | DI-2000 |
Internal Dimension (mm) | 800*1000*1000 | 1000*1000*1000 | 1000*1500*1000 | 1000*2000*1000 |
Overall Dimension (mm) | 1040*1450*1960 | 1330*1450*1960 | 1330*1950*1990 | 1330*2450*1990 |
Useful Volume (L) | 800 | 1000 | 1500 | 2000 |
Temperature Range | Ambient ~ +50℃ | |||
Humidity Range | < 30% RH | |||
Normal Wire Diameter | 50um | |||
Nominal Width of a Gap Between wires | 75um | |||
Fight Time | 0 ~ 99H59M | |||
Blowing Time | 0 ~ 99H59M | |||
Specimen Power Outlet | Dust-proof socket 16A | |||
Controller | Programmable color LCD touch screen controller, Ethernet connection | |||
Safety Device | Over-temperature Protection; Over-current Protection; Earth Leakage Protection; Phase Sequence Protection | |||
Exterior Material | A3 Steel Plate with protective coating | |||
Interior Material | SUS304 stainless steel | |||
Standard Configuration | Sample shelf, dust wiper, talcum powder(5kgs) | |||
Power | AC380V 50Hz |
