Standard
The Liquid Auto-Ignition Point Tester is engineered to meet ASTM E659, ISO 1516, and EN 14522 standards, ensuring precise determination of the lowest temperature at which a liquid vapor ignites spontaneously without an external ignition source. Ideal for petrochemical, pharmaceutical, and safety testing laboratories worldwide.
Product Advantages
- Unmatched Precision:
- Laser-guided temperature control (±0.1°C accuracy) for reliable auto-ignition point detection.
- Dual-mode testing: ramp (1–10°C/min) and isothermal methods to suit diverse liquid properties.
- Enhanced Safety:
- Explosion-proof stainless steel chamber with pressure relief valves and automatic gas shutoff.
- Real-time flammable vapor monitoring with audible/visual alerts.
- User-Friendly Operation:
- 5.7-inch color touchscreen with icon-driven menus and built-in tutorial videos.
- Preloaded ASTM/ISO test protocols for quick setup.
- Cost Efficiency:
- Modular design allows easy replacement of heating elements and sensors.
- Low energy consumption (≤800W during testing).
Product Features
- Testing Modes:
- Auto-ignition point (AIT) and flash point (closed-cup) determination in one unit.
- Supports volatile liquids, lubricants, solvents, and chemical intermediates.
- Temperature Control:
- Range: -30°C to 400°C (liquid-cooled system for sub-ambient tests).
- Heating rate: 0.1–10°C/min (programmable via software).
- Data Management:
- WiFi/USB connectivity for seamless integration with LabIgnite Pro Software.
- Automatic report generation with test curves and compliance certificates.
- Safety Compliance:
- ATEX Zone 1 certification for hazardous environments.
- CE, UL, and CSA approvals for global market access.
Technical Parameters
| Parameter | Specification |
|---|
| Temperature Range | -30°C to 400°C |
| Temperature Accuracy | ±0.1°C (AIT), ±0.5°C (flash point) |
| Heating Rate | 0.1–10°C/min (adjustable) |
| Chamber Material | 316L stainless steel (explosion-proof) |
| Power Supply | 220V/110V ±10%, 50/60Hz |
| Operating Environment | 5°C–40°C, ≤85% RH (non-condensing) |
| Dimensions (W×D×H) | 450 × 600 × 900 mm |
| Weight | 120 kg |
Accessories (Included)
- Testing Kits:
- Set of 3 closed-cup test vessels (ASTM/ISO/EN compatible).
- Replaceable ignition electrodes (2 sets).
- Safety Gear:
- Fire-resistant gloves, goggles, and lab coat.
- Emergency eyewash station (portable).
- Software Bundle:
- LabIgnite Pro (lifetime license) with cloud backup for 10,000+ test records.
- Spare Parts:
- 1x heating cartridge, 1x thermocouple, and 1x set of O-rings.
- Calibration Tools:
- NIST-traceable temperature calibration kit.
