Standard
The Konan Testing Instrument is designed and manufactured in compliance with ISO 7500-1, ASTM E4, and JIS B7721 standards, ensuring global applicability and reliability. It meets the stringent requirements of industries such as automotive, aerospace, construction, and materials science, providing certified accuracy for tension, compression, bending, and shear testing.
Product Advantages
- Unmatched Precision:
- Equipped with a high-resolution load cell (±0.5% accuracy) and closed-loop control system, delivering consistent results even for delicate materials.
- User-Centric Design:
- Intuitive 7-inch touchscreen interface with multi-language support (English, Spanish, German, Chinese).
- One-click test presets for common standards (ASTM D638, ISO 527, etc.).
- Durability & Safety:
- Robust alloy frame with corrosion-resistant coating, rated for 24/7 industrial use.
- Overload protection and emergency stop function to safeguard operators and samples.
- Cost Efficiency:
- Modular design reduces maintenance costs; 80% of components are field-replaceable.
Product Features
- Testing Capabilities:
- Supports tension, compression, flexural, peel, and shear tests.
- Max stroke: 1,000 mm (adjustable via software).
- Control System:
- Hybrid servo motor drive for silent operation (<50 dB) and 0.001–500 mm/min speed control.
- Data Management:
- Built-in WiFi/Bluetooth for real-time data transfer to PC/mobile devices.
- Compatible with KonanLab Pro Software for automated report generation (PDF/Excel formats).
- Safety Compliance:
- CE, RoHS, and FCC certified; meets EU machinery directive 2006/42/EC.
Technical Parameters
| Parameter | Specification |
|---|
| Max Load Capacity | 5 kN to 500 kN (customizable) |
| Load Accuracy | ±0.5% of indicated value |
| Crosshead Speed | 0.001–1,000 mm/min |
| Effective Test Space | 600 mm (W) × 1,200 mm (H) |
| Power Supply | 220V/110V ±10%, 50/60Hz |
| Operating Environment | 10°C–35°C, ≤80% RH (non-condensing) |
| Dimensions (W×D×H) | 550 × 700 × 1,800 mm |
| Weight | 280–450 kg (model-dependent) |
Accessories (Included)
- Standard Grips:
- Wedge grips (for metals/plastics), pneumatic grips (for textiles/films).
- Extensometers:
- Contacting (50/100 mm gauge length) and non-contacting (laser) options.
- Software Suite:
- KonanLab Pro (lifetime license) with cloud storage integration.
- Safety Kit:
- Laser safety curtains, anti-vibration pads, and dust covers.
- Spare Parts:
- 2x load cells, 1x set of replacement screws, and 1x emergency power-off module.
