Leakage trace tester

The Leakage Trace Tester is a precision diagnostic tool designed to visually identify and analyze fluid/gas leakage paths in sealed systems. It employs non-destructive testing methods, combining thermal imaging and dye penetration technology to highlight leaks with fluorescent or colored markers.

Type: Portable handheld device

Detection Sensitivity: 0.1μm micro-leaks

Working Modes: Fluorescent dye tracing / Smoke injection visualization

Power Supply: Rechargeable Li-ion battery (8h continuous operation)

Applications

Automotive: Fuel injector testing, brake system diagnostics

Industrial: Pipeline joint inspection, HVAC system leak mapping

Aerospace: Hydraulic fitting validation under pressure

Medical: Sterile seal integrity verification

Standards

ISO 10110-3: Optics and optical instruments - Preparation of drawings for optical elements and systems - Part 3: Material imperfections - Bubbles and inclusions

ASTM E1137: ：Standard Specification for Industrial Platinum Resistance Thermometers (PRTs)

CE EN 61010-1: Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 1: General requirements

Features

Dual Detection Modes:

Fluorescent Mode: Requires UV light for trace visualization

Smoke Mode: Generates visible vapor for pressurized systems

Smart Indicator System:

LED severity scale (green/yellow/red)

Audio alarm with dB level adjustment

Ergonomic Design:

Anti-slip rubberized grip

Rotatable 360° detection head

IP Rating: IP54 dust/water resistance

Parameters

Test Procedures

Surface Preparation: Clean test area with isopropyl alcohol

Dye Application: Apply UV tracer (0.5ml/cm²) for 15min dwell time

Inspection: Use 5W UV lamp at 30cm distance, scan at 45° angle

Post-Test: Neutralize residues with pH-balanced cleaner

Safety Precautions

Avoid direct eye exposure to UV light

Use PPE when handling flammable dye solutions

Maintain 1m clearance from open flames
