Paper Gypsum Board Fire Stability Tester

The Paper Gypsum Board Fire Stability Tester is a specialized laboratory instrument for evaluating the fire resistance of gypsum boards and other building or decorative materials. By applying controlled heat and loads, it quantitatively measures the time until sample failure under high-temperature conditions, providing objective data for material safety and certification purposes.

Application

Building Materials Testing and Certification

Testing institutions use this equipment to perform performance testing on fire-resistant materials such as gypsum boards, ensuring that products meet the requirements of standards such as GB/T9775-2008 and ISO6308. and providing internationally recognized test data for export products.

Product Development and Quality Control

Manufacturers optimize product formulations and processes through testing, for example, analyzing the impact of different inorganic fire-resistant fiber content on fire resistance performance, thereby enhancing product competitiveness.

Quality control is implemented during the production process to ensure that each batch of products meets fire safety standards.

Building Fire Protection Design and Safety Assessment

Architects and designers select materials with excellent fire resistance based on test results, for example, prioritizing gypsum boards with fire stability ≥30 minutes in high-rise buildings to improve the overall fire safety rating.

Fire safety experts use test data to assess building fire risks and develop targeted fire protection measures.

Research and Teaching Support

Research institutions analyze the fire resistance mechanisms of materials through systematic testing, for example, studying the impact of the bonding between facing paper and core material on fire stability, providing theoretical support for the industry.

Universities use this equipment for experimental teaching in materials science and engineering, cultivating students' practical abilities.

Expansion of Material Testing in Multiple Fields

In addition to gypsum boards, the equipment can also test the fire resistance performance of decorative and finishing materials such as tiles, metal sheets, and composite materials, forming a complete building materials fire resistance performance testing system.

Standard

GB/T9775-99：Gypsum plasterboard

Features

High Precision and Automation

Temperature Control: Precise temperature control is achieved through a PID control system, ensuring consistent testing conditions.

Data Recording: Automatically collects parameters such as temperature and time, generates dynamic curve graphs, and supports data storage and retrieval.

Automatic Ignition and Ventilation: Equipped with automatic ignition and a ventilation fan, ensuring timely removal of exhaust gases after testing and guaranteeing operational safety.

Modularity and Adaptability

Sample Support System: Adjustable support frame accommodates samples of different sizes, ensuring testing accuracy.

Multi-medium Testing: Supports the application of artificial sweat, grease, and other media to replicate complex usage environments.

Durability and Easy Maintenance

Stainless Steel Casing: High temperature resistance and corrosion resistance, suitable for long-term high-temperature testing environments.

Intuitive Operating Interface: Users can easily operate the device without complex training, and real-time data and process monitoring are provided during testing.

Parameters

Test Procedures

Sample Preparation: Cut the sample to the specified dimensions (e.g., 300 mm long × 50 mm wide), and process it under specified environmental conditions, such as drying to constant weight.

Sample Installation: Suspend the sample between two flame nozzles using support rods, with the nozzles perpendicular to the sample surface. Simultaneously, suspend a specified load from the lower end of the sample.

Ignition and Temperature Measurement: Ignite the burner, using liquefied petroleum gas as the heat source. Measure the temperature using a thermocouple at a specified distance from the sample surface (e.g., 5 mm).

Temperature Control: Adjust the temperature to (800 ± 30)℃ within 3 minutes, and maintain this temperature throughout the test.

Observation and Recording: Start timing from the moment the sample is exposed to the flame until it breaks or fails. Record the time it takes for each sample to burn through, using the minimum time among five samples as the fire resistance stability of that group of samples.

Conclusion

The Paper Gypsum Board Fire Stability Tester provides accurate, automated, and standard-compliant evaluation of fire resistance for gypsum boards and other building materials. It is suitable for laboratories, research institutions, production quality control, and fire safety design applications.

FAQ

1. What is this product?

It is a laboratory testing device to measure the fire stability and resistance of gypsum boards and related building materials.

2. What is this product used for?

To determine the duration a material can withstand high-temperature flame before breaking, providing fire resistance data for certification, research, and design.

3. What is the working principle of this product?

Samples are suspended between burners under a specified load while exposed to controlled high-temperature flames. Time until failure is measured to evaluate fire resistance.

4. Why is this product important?

It ensures building materials meet fire safety standards, informs material selection for construction, and supports compliance with national and international regulations.

5. What industries is this product suitable for?

Construction materials testing, building safety assessment, research institutions, universities, and fire protection certification laboratories.
