Product Introduction:Wire bending tester meets JIS-C-3005 test standard. The sample is inserted thro
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
Wire bending tester meets JIS-C-3005 test standard. The sample is inserted through the specified round hole according to thickness, and fixed in the fixture with adjusted spacing. After rotating the wheel 200 times, the degree of damage, cracking, crack and conductor strand breakage rate are checked. It has the characteristics of simple operation and excellent performance, can be positive and negative operations, and cn be set to automatically stop after reaching the number of times.
JIS-C-3005, UL 87
1. Fixture action: manual
2. Fixture spacing: 0——500mm adjustable
3. The total number of times: 0-999999 times can be manually set
4. Test rate: 20 times/min
5. Off-center: 50. 75. 100. 150mm
6. The diameter of the parallel section of the sample: φ4mm, φ6mm, φ8mm, φ10mm, φ12mm,φ15mm, φ18mm, φ20mm
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
