ApplicationThis machine is used to test the rubbing resistance for shoelace of cotton, hemp, ch
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
This machine is used to test the rubbing resistance for shoelace of cotton, hemp, chemical fiber or other materials.
This machine is designed for the resistance of all shoelaces to abrasion. Two shoelaces are horizontally crossed in a moveable clamp, rubbing against each other, so as to determine their abrasive resistance.4 sets of specimens can be tested once.
| Test position | 4 groups |
| Control | Touch-screen control, 0~999.999 |
| Min. Separation between movable and fixed fixtures | 280 ±50 mm |
| Movable fixture stroke | 35± 2 mm |
| Test speed | 60 ± 6 cyles/min |
| Profile board | Angle 52.5degree; Length120 mm |
| Stainless metal strip | W: 25mm, L: 250mm |
| Weight | 250 ± 3g |
| Power supply | 1phase AC 220V 50/60HZ |
| Dimensions ( L x W x H ) | 66 x 58 x 42cm |
| Weight | 50 kg |
| Standards | DIN 4843 SATRA TM 154 ISO 22774 QB/T 2226 |
