1. Salt fog chamber cover adopts inverted triangular groove design, spray condensation water can be flowed to sides, will not affect the test piece.
2. The material of salt fog chamber has a big update for older material PVC with stronger corrosion and high temperature resistance, one-time forming, reinforced design, long service life.
3. The salt fog environment is stable, and the concentration, temperature, humidity and other key parameters of the salt spray can be maintained within the set range for a long time. Ensure that the corrosive effect on the material is uniform and predictable.
4. Salt fog chamber can carry out NSS, AASS and CASS test and meet the requirements of basic and continuous salt spray test.
5. More than 16 different models of salt fog corrosion chambers are available for all types of product testing, while also supporting customization.
① Workroom | the standard sample rack is a round rod and V-shaped slot, and the placement Angle of test parts can be adjusted. Custom sample holders are also available for special-shaped test pieces. Once the workroom lid is closed, seal it with water to further prevent salt spray leaks. |
② Salt spray collector | Measuring the settling amount of salt spray is mainly composed of funnel cups and conduits. After the salt spray condenses into water in the funnel cup, it flows through the pipe to the measuring cylinder outside the salt fog chamber for reading and recording the settling amount of the salt spray. |
③ Spray tower | Make sure the salt spray is evenly distributed throughout the workroom. Quartz nozzle inside. |
④ Heater strip | Located at the bottom of the workroom, it provides the required heat for the workroom. |
⑤ Controller | Set and control test parameters, such as temperature, spray time, test period, etc. At the same time, the running state of the salt fog corrosion chamber is monitored and controlled in real time, and the alarm signal is sent when abnormal conditions occur. |
⑥ Salt solution tank | The brine solution required for the salt spray test is stored and supplied, and the salt tank is equipped with a stirring device to ensure a uniform brine concentration. |
⑦ Saturated barrel | The air entering the spray tower is filtered, warmed and humidified so that the air reaches a saturated state and then transported to the nozzle for spraying. |
⑧ Air source | Compressed air is provided to the salt spray test chamber as the power source of salt spray injection. |
Model | STD S-150 | STD S-250 | STD S-750 | STD S-010 |
Internal dimensions (mm) | 590*470*400 | 1000*640*500 | 1100*750*500 | 1000*1300*600 |
Overall dimensions (mm) | 1460*760*1140 | 1850*960*1350 | 1950*1030*1350 | 2000×1300×1600 |
Interior Volume (L) | 110 | 320 | 410 | 780 |
Temperature Range | Ambient ～ +60 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 95% ~ 98% RH | |||
Salt Fog Deposition | 1～2ml / 80cm2 · h | |||
Spray Type | Continuous / Periodic | |||
Salt Fog Collected | Fog collector and fog measure cylinder | |||
Air Preheating | Saturated air barrel | |||
Spraying System | Atomizer tower and Spray nozzles | |||
Controller | PID controller | |||
Safety Device | Humidifier Dry-combustion Protection; Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection | |||
Material | Glass fiber reinforced plastics | |||
Standard Configuration | 6 round bars and 5 V-shaped grooves | |||
