Features and Benefits1. The temperature of vacuum ovens can be heating up to+250℃.2. The vacuum
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. The temperature of vacuum ovens can be heating up to+250℃.
2. The vacuum pump has been built into the cabinet of the oven. Vacuum control range to -133pa.
3. Programmed control can realize precise control and automatic operation.
4. This vacuum oven is energy efficient and promotes great temperature uniformity.
Model | STD VO-20 | STD VO-30 | STD VO-50 | STD VO-90 | STD VO-125 |
Internal Dimension (mm) | 300x300x275 | 320x320x300 | 415x370x345 | 450x450x450 | 500x500x500 |
Overall Dimension (mm) | 610x490x450 | 630x510x490 | 730x560x550 | 740x610x595 | 790x660x645 |
Interior Volume | 20L | 30L | 50L | 90L | 125L |
Temperature Range | +35 ℃ ～+350 ℃ | ||||
Heating Rate | 6 ℃ / min | ||||
Vacuum degree | -133pa | ||||
Heating Element | Nichrome heater | ||||
Controller | Programmable color LCD touch screen controller | ||||
Ethernet connection, PC Link(Option) | |||||
Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class | ||||
View Window Size(mm) | 120*150 | ||||
Safety Device | Over-temperature Protection; Over-current Protection; Earth leakage Protection, Phase Sequence Protection | ||||
Exterior Material | Steel Plate with protective coating | ||||
Interior Material | SUS316 stainless steel | ||||
Thermal Insulation | Polyurethane foam | ||||
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | ||||
Vacuum pump | Built-in vacuum connection tube and vacuum pump | ||||
Standard Configuration | 2 shelves | ||||
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
