1. Precise Control
Advanced system with ±0.1°C temperature accuracy and ±2.5%RH humidity accuracy. Nichrome heater and stainless steel humidifier ensure stable performance.
2. Uniform Conditions
Top-mounted fan provides effective air circulation for consistent temperature and humidity throughout the chamber.
3. Energy Efficient
Uses polyurethane foam insulation to reduce energy consumption and operating costs, supporting eco-friendly operation.
4. Wide Application
Suitable for electronics, automotive, chemical, biomedical, and other industries to meet diverse testing requirements.
Model | STD TH-100 | STD TH-500 | STD TH-800 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 700*800*900 | 800*1000*1000 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1200*1340*2020 | 1300*1540*2120 | 1500*1540*2140 |
Interior Volume | 100L | 500L | 800L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Cooling system | Mechanical compression refrigeration system | |||
Controller | Programmable color LCD touch screen controller, Ethernet connection | |||
Water supply system | Automatic water supply, Water purification system | |||
Safety Device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection; Earth leakage protection | |||
Exterior Material | Steel Plate with protective coating | |||
Interior Material | SUS304 stainless steel | |||
