Features and Benefits1. Real-time temperature monitoring, temperature range can be customized t
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Real-time temperature monitoring, temperature range can be customized to +1000 ° C, +1200 ° C, accuracy ±0.5 ° C, uniform distribution ±2%.
2. The programmable PID control system supports multi-stage temperature curves for complex loop testing.
3. The enhanced thermal efficiency reduces heating time and minimizes energy consumption.
4. Flexible workroom size and adjustable sample holder to accommodate various battery types and component sizes.
5. High temperature performance testing, thermal aging and durability assessment, safety certification testing, material compatibility analysis.
Model | STD O-100 | STD O-225 | STD O-500 | STD O-800 | STD O-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 800*1000*1000 | 1000*1000*1000 |
Overall Dimension (mm) | 750*880*850 | 800*950*1000 | 1100*1100*1300 | 1100*1450*1400 | 1300*1400*1400 |
Interior Volume | 100L | 225L | 500L | 800L | 1000L |
Temperature Range | A: Ambient ～+250 ℃ B: Ambient ～+400 ℃ C: Ambient ～+900 ℃ | ||||
Temperature Fluctuation | ± 0.5 ℃ | ||||
Temperature Deviation | ± 2.0 ℃ | ||||
Heating Rate | 6 ℃ / min | ||||
Heating Element | Nichrome heater | ||||
Controller | Programmable color LCD touch screen controller, Ethernet connection | ||||
Safety Device | Over-temperature Protection; Over-current Protection; Phase Sequence Protection; Earth leakage Protection | ||||
Exterior Material | Steel Plate with protective coating | ||||
Interior Material | SUS304 stainless steel | ||||
Thermal Insulation | Polyurethane foam （Refractory brick） | ||||
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | ||||
Standard Configuration | 2 shelves | ||||
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
