Features and Benefits1. Accurately control the temperature, humidity and other environmental pa
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Accurately control the temperature, humidity and other environmental parameters. Other environmental factors can also be customized for collaborative testing of test pieces.
2. The relatively independent closed space effectively avoids the interference of external environmental factors, which makes more pure simulation.
3. The experimental results are accurate and the data are more accurate and repeatable.
4. The application range is wide, including but not limited to scientific research, industrial product quality testing, agriculture, cultural relics protection, etc.
Model | STD TH-100 | STD TH-225 | STD TH-500 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Controller | Programmable color LCD touch screen controller,PC Link, R-232 interface | |||
Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class | |||
Humidity sensor | Dry and wet bulb sensor | |||
Heater | Nichrome heater | |||
Cooling system | Mechanical compression refrigeration system | |||
Refrigerating unit | French TECUMSEH compressor | |||
Refrigerant | Environmentally friendly refrigerant | |||
Humidifier | External isolation, stainless steel surface evaporation humidifier | |||
Dehumidification system | Evaporator | |||
Air circulation | Centrifugal wind fan | |||
Water supply system | Automatic water supply; Water purification system | |||
Safety device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | |||
Exterior material | Steel Plate with protective coating | |||
Thermal insulation | Polyurethane foam | |||
Observation window | Interior lighting , double-layer thermo stability silicone rubber sealing | |||
Standard configuration | 1 Cable hole (Φ 50.) with plug; 2 shelves | |||
Timing Function | 0.1~999.9 (S,M,H) settable | |||
