Features and Benefits1. Custom systems, the size and performance can be customized according to
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Custom systems, the size and performance can be customized according to the customer's needs.
2. Automatically fill sand or dust, automatically distributes sand or dust over time. Automatic temperature & humidity control.
3. All these parameters can be programmed using the programmable colour touch screen controller, can be connected to the computer and the laboratory operating system, so as to achieve remote control.
4. After effectively communicating with the customer about the test requirements, the model can be accurately designed and the blowing sand test chamber can be delivered quickly.
Model | STD DIM-1000 |
Internal Dimension | 1000*1000*1000mm D*W*H |
Overall Dimension | 3000*6100*2200mm D*W*H |
Interior Volume | 1000L |
Blowing Dust | |
Air velocity | 1.5 -8.9m/s |
Concentration of dust | 10.7±7g/ m³ |
Dust particles | ＜ 150μm |
Blowing sand | |
Air velocity | 18.0 -29.0m/s |
Concentration of sand | 0.18+0.2g/m³; 1.1+0.3g/m³; 2.2+0.5g/m³ |
Sand particles | 149μm - 600μm, 600μm - 850μm |
Controller | Programmable color LCD touch screen controller, Ethernet connection |
Testing Platform Diameter | 600mm |
Door Lock | Electromagnetic lock |
Testing Platform Speed | 1-7 r.p.m |
Dust Detector | Integrated dust detector |
Exterior Material | A3 Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
Standard | MIL-STD- 810 |
