Features and Benefits1. The spectra of the xenon arc lamp and sunlight are highly convergent.Xe
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. The spectra of the xenon arc lamp and sunlight are highly convergent.Xenon arc exposure apparatus adopts quartz globe sealing and filtration technology to precisely regulate its spectral energy distribution.
2. Xenon arc exposure apparatus can simulate complex natural environment, controlled temperature and humidity, light and spray system.
3. The uniformity of light intensity is high, which ensures that the light energy received by each part of the test sample is relatively consistent.
4. Utilized in textiles, dyes, leather, plastics, paints, coatings, automotive interior parts, electro technical products, color building materials.
Model | STD XL-S-750 |
Internal Dimension (mm) | 950*950*850 mm |
Overall Dimension (mm) | 1400*1400*1950 mm |
Specimen Holder Size(mm) | 95*200 |
Specimen Capacity | 42pcs |
Chamber Type | Rotating Holder |
Irradiation Source | 1 piece of 4500w water-cooled xenon arc lamp |
Irradiance Range | 35~150 W/㎡ |
Bandwidth Measurement | 300nm~400nm (340nm or 420nm) |
Chamber Temperature Range | Ambient ～ 100 ℃ ±2℃ |
Black Panel Temperature | BPT 35 ～ 85 ℃ ±2℃ |
Humidity Range | 50% ~ 98% RH |
Humidity Deviation | ± 5% RH |
Water Spray Cycle | 1~9999H59M (Adjustable) |
Controller | Programmable color LCD touch screen controller |
Water supply system | Automatic water supply, Water purification system |
Radiometer | UV Radiometer, Tolerance: ±5% |
Cooling System | Mechanical compression refrigeration system |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
