1. Accelerated Aging Simulation
Simulates months or years of outdoor UV exposure in just a few days or weeks. Ideal for assessing long-term durability of materials under harsh environments.
2. Stable and Repeatable Conditions
Equipped with fluorescent UV lamps (UVA-340. UVB-313) that provide consistent irradiance (typically 0.68–1.55 W/m² at 340nm), ensuring high repeatability and reliability of results.
3. Customizable Test Cycles
Supports a variety of test cycles combining UV light, condensation, and spray. Typical cycles follow ASTM G154 or ISO 4892-3 with programmable settings.
4. Energy-Efficient Design
Fluorescent UV lamps consume less energy and have longer lifespans (up to 1600 hours), reducing operational costs.
Model | STD UV-SI-260 |
Internal Dimension (mm) | 450*1170*500 |
Overall Dimension (mm) | 610*1330*1470 |
Specimen Holder Size(mm) | 75*150 |
Specimen Capacity | 56 Pieces |
Irradiation Source | Fluorescent UV lamps (8) - 40 W |
Temperature Range | Ambient ～ 90 ℃ ±2℃ |
Black Panel Temperature (BPT) | 35 ～ 80 ℃ |
Humidity Range | ≥95% RH |
Bandwidth | 290 ~ 400nm |
Irradiance Control | 0.3~20 W/㎡ |
Water Spray Cycle | 1~9999H59M (Adjustable) |
Distance of Specimen and lamp | 50mm |
Controller | Programmable color LCD touch screen controller, Ethernet connection |
Water Supply System | Automatic water supply, Water purification system |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
Exterior Material | Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
