Features and Benefits1. Accelerated aging testing can simulate the aging effect of materials in
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Accelerated aging testing can simulate the aging effect of materials in natural environments for years within tens or hundreds of hours, accelerating the detection of materials' UV and weather resistance.
2. The UVA-340 or UVB-313 tubes, and the output wavelengths are concentrated around 340 nm or 313 nm respectively, which complies with standards such as ASTM G154 and ISO 4892-3.
3. The temperature can be controlled. It is also equipped with condensation and water spray functions to simulate the real day-night temperature difference and humidity cycle.
4. Supports light/condensation cycle, effectively simulating the alternating environment of direct sunlight during the day and high humidity condensation at night outdoors, accelerating the detection of surface aging, cracking and fading.
Model | STD UV-SI-260 |
Internal Dimension (mm) | 450*1170*500 |
Overall Dimension (mm) | 610*1330*1470 |
Specimen Holder Size(mm) | 75*150 |
Specimen Capacity | 56 Pieces |
Irradiation Source | Fluorescent UV lamps (8) - 40 W |
Temperature Range | Ambient ~ 90 ℃ ±2℃ |
Black Panel Temperature (BPT) | 35 ~ 80 ℃ |
Humidity Range | ≥95% RH |
Bandwidth | 290 ~ 400nm |
Irradiance Control | 0.3~20 W/㎡ |
Water Spray Cycle | 1~9999H59M (Adjustable) |
Distance of Specimen and lamp | 50mm |
Controller | Programmable color LCD touch screen controller, Ethernet connection |
Water Supply System | Automatic water supply, Water purification system |
Safety Device | Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection; Phase Sequence Protection |
Exterior Material | Steel Plate with protective coating |
Interior Material | SUS304 stainless steel |
