Automatic Positioning Gantry UTM

1. Product Function and Application

The Automatic Positioning Gantry Universal Testing Machine (UTM) provides automated 4-axis control for tension and compression testing of materials such as foams, polymers, textiles, and automotive interior components. Using proprietary software, it enables programmable sequential positioning and precise force/displacement measurement, supporting industry-standard testing methods.

The system automatically calculates Support Factor and Ultimate Elongation per ASTM D3574-11, ensuring accurate and repeatable data for foam and flexible material analysis.

2. Applicable Test Standards

ASTM D3574-11 Test B1 – Support Factor (25% & 65% Load)

ASTM D3574-11 Test E – Ultimate Elongation

ASTM D3574-11 X3 – Support Factor definition and calculation method

3. Technical Specifications

4. Product Advantages and Features

Automated 4-axis control for precise positioning and repeatable test procedures.

Dual-mode operation for both tension and compression tests.

Fully programmable testing sequence and data acquisition.

Automatic ASTM D3574-11 calculations for Support Factor and Ultimate Elongation.

Customizable configurations for stroke length, speed, and load capacity.

Safety-first design with emergency stop to protect operator and equipment.

Optional software customization for specialized testing requirements.

Durable and precision-engineered aluminum and stainless steel construction.
