Features and Benefits1. Complies with multiple international testing standards such as IEC 6052
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Complies with multiple international testing standards such as IEC 60529(IP5X/IP6X), ISO 20653, and SAE J575. It can also meet the more stringent sand and dust test requirements of industries such as automobiles and military industry.
2. LIB can customize large-capacity models like walk-in dust exposure test equipment according to customer requirements to meet the testing needs of large samples such as complete vehicles and communication cabinets.
3. The centrifugal fan and the air diversion structure precisely regulate the internal airflow. At the same time, combined with the dust recirculation technology, it ensures the uniform distribution of dust.
4. Multiple standard models such as DI-800, DI-1000, DI-1500, DI-2000, etc. can be delivered quickly and comply with international certifications such as CE and ISO.
Model | DI-800 | DI-1000 | DI-1500 | DI-2000 |
Internal Dimension (mm) | 800*1000*1000 | 1000*1000*1000 | 1000*1500*1000 | 1000*2000*1000 |
Overall Dimension (mm) | 1040*1450*1960 | 1330*1450*1960 | 1330*1950*1990 | 1330*2450*1990 |
Useful Volume (L) | 800 | 1000 | 1500 | 2000 |
Temperature Range | Ambient ~ +50℃ | |||
Humidity Range | < 30% RH | |||
Normal Wire Diameter | 50um | |||
Nominal Width of a Gap Between wires | 75um | |||
Fight Time | 0 ~ 99H59M | |||
Blowing Time | 0 ~ 99H59M | |||
Specimen Power Outlet | Dust-proof socket 16A | |||
Controller | Programmable color LCD touch screen controller, Ethernet connection | |||
Safety Device | Over-temperature Protection; Over-current Protection; Earth Leakage Protection; Phase Sequence Protection | |||
Exterior Material | A3 Steel Plate with protective coating | |||
Interior Material | SUS304 stainless steel | |||
Standard Configuration | Sample shelf, dust wiper, talcum powder(5kgs) | |||
Power | AC380V 50Hz |
