Applicable standards:GB 11550-2009 "Car seat headrest strength requirements and test methods" : This
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
The Car Seat Static Strength Tester is a dedicated testing system used to evaluate the static load-bearing strength of automotive seats, seat fixtures, and headrests under controlled force application.
By applying specified static loads and measuring deformation, displacement, and angular variation, the tester verifies whether seat structures comply with regulatory strength and durability requirements.
The system is widely used for type approval testing, OEM validation, quality control, and R&D evaluation in automotive seating applications.
(1) Static strength testing of complete automotive seat assemblies.
(2) Load-bearing performance evaluation of seat backs under forward and backward static forces.
(3) Static load testing of seat cushions and supporting structures.
(4) Strength verification of headrests under prescribed static loading conditions.
(5) Static strength testing of seat fixtures, seat rails, and mounting brackets.
(6) Structural deformation measurement of seat frames under sustained load.
(7) OEM certification and regulatory compliance testing for automotive seating systems.
(8) Quality inspection and consistency verification during seat mass production.
(9) Comparative strength testing of different seat designs or structural materials.
(10) R&D validation for newly developed seat structures and reinforcement solutions.
(1) GB 15083-2006 – Automobile seats, seat fixtures, and headrest strength requirements and test methods.
(2) GB 11550-2009 – Strength requirements and test methods for automotive seat headrests.
(3) FMVSS 207 – Seating systems strength requirements (static load tests).
(4) ECE R17 – Strength and safety requirements for vehicle seats and head restraints.
(5) ISO 6549 – Road vehicles – Procedure for H-point determination (related seat structural evaluation).
(6) EN 71-1 – Mechanical and physical properties (reference for static mechanical safety testing).
(7) OEM internal standards and enterprise technical specifications for seat static strength testing.
(1) Designed for static strength testing of seats, headrests, and seat fixtures.
(2) Wide load measurement range suitable for various seat structures and components.
(3) High load accuracy ensures reliable and repeatable test results.
(4) Long cylinder stroke supports full displacement and deformation measurement.
(5) High-precision displacement and angular measurement for detailed structural analysis.
(6) High sampling frequency captures complete load–displacement behavior.
(7) Professional test software supports manual and automatic control modes.
(8) Advanced data processing functions including curve analysis and slope calculation.
(9) Robust mechanical structure ensures stability during high-load static testing.
(10) Integrated safety protection for secure and controlled operation.
| Parameter | Specification |
|---|---|
| Load Measurement Range | 40–2000 N (model-dependent) |
| Load Accuracy | ±1% |
| Load Cylinder Stroke | Up to 500 mm |
| Displacement Accuracy & Resolution | High-precision for accurate measurement |
| Angular Displacement Accuracy | ±0.01° |
| Sampling Frequency | ~1000 Hz |
| Power Supply | Single-phase AC 220V, 50Hz |
| Software Functions | Test control, curve feature analysis, slope calculation, curve scaling, data export to Excel |
Adjustable fixtures for different seat types and sizes
High-precision load cells for extended measurement range
Advanced data acquisition and analysis software
Protective covers and anti-vibration mounting base
Calibration kits for sensors and cylinders
(1) Install the seat, headrest, or fixture on the test bench using the appropriate mounting fixture.
(2) Connect load, displacement, and angular sensors and verify system zero calibration.
(3) Set test parameters including load value, loading direction, and cylinder stroke.
(4) Start the test; the system applies static load according to the selected program.
(5) Monitor load, displacement, and angular changes in real time.
(6) Complete the test and release the load gradually.
(7) Save, analyze, and export test data and curves for evaluation and reporting.
(1) Regularly inspect load cylinders, mechanical structures, and fixtures for wear or deformation.
(2) Periodically calibrate load cells, displacement sensors, and angular measurement devices.
(3) Keep control electronics, sensors, and cables clean and dry.
(4) Check safety protection devices and emergency stop functions before operation.
(5) Lubricate moving mechanical components according to the maintenance schedule.
(6) Store the equipment in a clean, stable environment when not in use.
