ISO 18895-2006 LCD Display 0~99,999,999 Steel Hook Fatigue Testing Machine

Standards compliant

ISO 18895-2006

Technical parameters

Lower clamp: fixed, with hard steel plane, height 32mm ± 2mm

Distance between upper clamp link and lower clamp: 70mm±2mm

Rate: 4r/s

Applied to the sample circulation force: 49N ± 2N

Control fixture clamp clamping force: 4900N.mm±50 N.mm

Counter: LCD display 0~99.999.999

With automatic stop function, when the set number of times arrives, it will automatically stop

It has the function of automatic shutdown of the test piece.

Use

Test the resistance of various footwear to the repeated alternating load under the specified conditions.
