StandardsDIN 4551. EN 1335. NEN 1812.BIFMA X5.1. BSI/BS 5459. EN 581-2Test StandardsStanda
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
DIN 4551. EN 1335. NEN 1812.
BIFMA X5.1. BSI/BS 5459. EN 581-2
| Standard | section | Test Items |
| QB/T 2280-2016 | 6.6.2 | 座面冲击 |
| 6.6.12.1 | 座面往复冲击耐久性 | |
| BIFMA X5.1-2017 | 7 | Drop Test - Dynamic |
| 10.3 | Impact Test | |
| BIFMA X5.4-2020 | 14 | Seating Durability Tests - Cyclic |
| 15 | Drop Test - Dynamic | |
| BIFMA X5.9-2019 | 7.2 | Drop Test - Dynamic - for Units with Seat Surfaces |
| 7.3 | Durability Test for Units with Seating Surfaces - Cyclic Impact | |
| EN 1728:2012 | 6.24 | Seat impact test |
| 8.8 | Impact test | |
| EN1730:2012 | 6.6.3 | Vertical impact test for all other table tops |
| Impact weight | 136kg |
| Seat height | 30~65cm |
| Loading times | 0~99999times,adjustable |
| Strength adjust | pressure adjust |
| Control | PLC, text display |
| Beams lifting way | Electric lift |
| Air supply | kgf/cm^2 or above,customer provides it for himself |
| Power | AC 220V 50Hz 5A |
| Dimension | 2.8L*1.2W*1.8H m |
| Accessories | Impact Bags, Weights, Fixture |
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
