Features and Benefits1. The independent temperature zone design and high-precision temperature
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. The independent temperature zone design and high-precision temperature sensor ensure rapid and uniform temperature conversion
2. Complies with international test standards such as MIL-STD, IEC and JEDEC, and is an ideal choice for high-reliability environmental stress screening (ESS) tests.
3. The samples are automatically switched without the need to open the door to change zones, avoiding the leakage of cold and hot air. The testing process is more continuous and energy-efficient.
4. The sample can switch rapidly between two temperature zones (within 3 seconds), enabling multiple cycles to be completed in a short period of time, enhancing testing efficiency and shortening the product verification cycle.
Model | STD TS-162 | STD TS-340 | STD TS-500 | STD TS-1000 | |
Internal Dimensions (mm) | 300*300*250 | 450*450*360 | 650*650*500 | 850*850*700 | |
Overall Dimension (mm) | 1560*870*1545 | 1710*1020*1845 | 1910*1220*2265 | 2110*1420*2665 | |
Interior Volume (mm) | 22L | 72L | 211L | 505L | |
Loading Capacity | 20kg | 30kg | 50kg | 60kg | |
Pre-heat Room | Upper limit Temperature | +220℃ | |||
Heating Time | Ambient ~ + 200℃, within 30 minutes | ||||
Pre-cool Room | Lower limit Temperature | -75℃ | |||
Cooling time | Ambient ~ -70℃, within 30 minutes | ||||
Test Room | High Temperature Exposure Range | Ambient +20 ~ +200°C | |||
Low temperature Exposure Range | –65 ~ -5°C | ||||
Temperature Fluctuation | ≤±0.5℃ | ||||
Temperature Deviation | ≤±3 ℃ | ||||
Temperature Recovery Time | Within 5 minutes | ||||
Cooling System | Mechanical compression refrigeration system，environmentally friendly refrigerant | ||||
Controller | Programmable color LCD touch screen controller, Ethernet connection | ||||
