1. Wide temperature and humidity range, suitable for various extreme environments,it can simulate complex environments from tropical high temperatures to polar cold,
2. PID control system, featuring high temperature and humidity control accuracy (temperature ±0.5°C, humidity ±2.5%RH), and supports functions such as condensation control and condensation simulation.
3. Comply with multiple international testing standards such as IEC 60068. MIL-STD-810. ISO 16750. etc., and is applicable for electronics, automobiles, military industry, semiconductors, etc.
4. Flexible configuration, supporting customized function expansion such as remote monitoring, program setting, multi-sample testing, cable holes, and rapid cooling with liquid nitrogen.
Model | STD TH-100 | STD TH-225 | STD TH-500 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Controller | Programmable color LCD touch screen controller,PC Link, R-232 interface | |||
Temperature Sensor | PTR Platinum Resistance PT100Ω/MV A-class | |||
Cooling system | Mechanical compression refrigeration system,French TECUMSEH compressor,environmentally friendly refrigerant. | |||
Air circulation | Centrifugal wind fan | |||
Water supply system | Automatic water supply; Water purification system | |||
Safety device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection, Earth leakage protection; | |||
Observation window | Interior lighting , double-layer thermo stability silicone rubber sealing | |||
Standard configuration | 1 Cable hole (Φ 50.) with plug; 2 shelves | |||
Timing Function | 0.1~999.9 (S,M,H) settable | |||
