Features and Benefits1. The temperature of STD ovens can be heating up to+250℃, +500℃, +800℃, +
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. The temperature of STD ovens can be heating up to+250℃, +500℃, +800℃, + 1000℃, + 1200℃. Ovens with different temperatures have completely different structures to maximize its functions.
2. Safety protection is mainly embodied in two aspects, one is product current, grounding, over temperature and phase loss protection. The second is to use thickened A3 steel plates to isolate the heating components to prevent the operator from accidentally touching the heating tube and causing damage.
3. Programmed control can realize precise control and automatic operation.
Model | STD O-100 | STD O-225 | STD O-500 | STD O-800 | STD O-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 800*1000*1000 | 1000*1000*1000 |
Overall Dimension (mm) | 750*880*850 | 800*950*1000 | 1100*1100*1300 | 1100*1450*1400 | 1300*1400*1400 |
Interior Volume | 100L | 225L | 500L | 800L | 1000L |
Temperature Range | A: Ambient ～+250 ℃ B: Ambient ～+400 ℃ C: Ambient ～+900 ℃ | ||||
Temperature Fluctuation | ± 0.5 ℃ | ||||
Temperature Deviation | ± 2.0 ℃ | ||||
Heating Rate | 6 ℃ / min | ||||
Heating Element | Nichrome heater | ||||
Controller | Programmable color LCD touch screen controller, Ethernet connection | ||||
Safety Device | Over-temperature Protection; Over-current Protection; Phase Sequence Protection; Earth leakage Protection | ||||
Exterior Material | Steel Plate with protective coating | ||||
Interior Material | SUS304 stainless steel | ||||
Thermal Insulation | Polyurethane foam （Refractory brick） | ||||
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | ||||
Standard Configuration | 2 shelves | ||||
