Features and Benefits1. Through extreme conditions such as high temperature/humidity, the natur
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
1. Through extreme conditions such as high temperature/humidity, the natural aging cycle (years) is reduced to weeks and the shelf life of the product is quickly verified.
2. Reduce the labor, space and time consumption of long-term storage testing, reducing the cost of research and development and quality inspection.
3. Temperature and humidity accuracy of ±0.5℃/±2%RH, can also be customized other functional modules such as lighting, simulate complex environmental conditions.
4. Covering food, medicine, electronics, automotive and other fields, verify the aging resistance of materials, packaging and finished products.
Model | STD TH-100 | STD TH-225 | STD TH-500 | STD TH-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Humidity Range | 20% ~ 98% RH | |||
Humidity Deviation | ± 2.5% RH | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Cooling system | Mechanical compression refrigeration system | |||
Controller | Programmable color LCD touch screen controller Ethernet connection | |||
Safety Device | Humidifier Dry-combustion protection; Over-temperature Protection; Over-current Protection; Refrigerant High-pressure protection; Water Shortage Protection; Earth leakage Protection | |||
Exterior Material | Steel Plate with protective coating | |||
Interior Material | SUS304 stainless steel | |||
Thermal Insulation | Polyurethane foam and insulation cotton | |||
Observation Window | Interior lighting, double-layer thermo stability silicone rubber sealing | |||
Standard Configuration | 1 Cable hole (Φ 50.) with plug; 2 shelves | |||
