1. Using advanced temperature control system and high-precision temperature sensor, the temperature can be accurately controlled at the set value with 0.001 degree temperature accuracy up to ±0.1℃.
2. Through the air duct system, circulating fans, the temperature of each point in the chamber is evenly distributed, and the temperature difference is within ±2 ° C.
3. 10CM high-quality thermal insulation materials and thermal insulation structure to reduce heat loss, reduce energy consumption, and maintain internal temperature stability.
4. Different chamber sizes models meet the diverse needs of use and the adjustable sample shelf is convenient for the placement and classification of items.
Model | STD T-100 | STD T-225 | STD T-500 | STD T-1000 |
Internal Dimension (mm) | 400*500*500 | 500*600*750 | 700*800*900 | 1000*1000*1000 |
Overall Dimension (mm) | 900*1050*1620 | 1000*1140*1870 | 1200*1340*2020 | 1500*1540*2140 |
Interior Volume | 100L | 225L | 500L | 1000L |
Heat load | 1000W | |||
Temperature Range | A : -20℃ ～ +150 ℃ B : -40℃ ～ +150 ℃ C: -70℃ ～ +150 ℃ | |||
Temperature Fluctuation | ± 0.5 ℃ | |||
Temperature Deviation | ± 2.0 ℃ | |||
Cooling Rate | 1 ℃ / min | |||
Heating Rate | 3 ℃ / min | |||
Cooling system | Mechanical compression refrigeration system | |||
Refrigerating unit | French TECUMSEH compressor | |||
Heating Element | Nichrome heater | |||
Controller | Programmable color LCD touch screen controller, Ethernet connection | |||
Water supply system | Automatic water supply, Water purification system | |||
Safety Device | Over-temperature protection; Over-current protection; Refrigerant high-pressure protection; Earth leakage protection | |||
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
