FeatureWhole chamber inside and gripers made up of stainless steel, anti-corrosion.Outside of t
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
Whole chamber inside and gripers made up of stainless steel, anti-corrosion.
Outside of the chamber is baking finish (can choose SUS 304 stainless steel)
Whole machine equipped with a safety protection system, the end of the test automatically stops
Use low-noise, multi-wing centrifugal fan to supply air circulation to avoid any dead angle, which can evenly distribute temperature and humidity and ozone in the test area.
The test door and body are sealed with double layer ozone resistant high tensile silica gel to ensure the sealing of the test area
With a transparent window, chamber inner with a lamp, used to observe changes of samples.
Capacity | 80L | 150L | 225L | 408L | 800L | 1000L |
Inside dimension (W×H×D, cm) | 40×50×40 | 50×60×50 | 50×75×60 | 60×85×80 | 100×100×800 | 100×100×100 |
Outside dimension (W×H×D, cm) | 95×136×94 | 100×146×104 | 100×161×117 | 110×171×137 | 150×186×137 | 150×186×157 |
Model | STD-AC22 Ozone Test Chamber |
Ozone concentration | 0～1000 PPHM |
Ozone concentration deviation | ≤10％ |
Chamber temperature | 0～80℃, can be set |
Chamber humidity | 20%~98%, can be set |
Specimen frame rotation velocity | 0～50mm/s |
Chamber gas-flow rate | 8-16mm/s |
Material of inner surface | SUS304 mirror finished stainless steel |
Material of outside surface | baking finish surface or SUS304 stainless steel, option |
