StandardISO 10555 (Seat Belt Assemblies - Test Methods for Abrasion Resistance)ECE R16 (Uniform Prov
WhatsApp : +86 13816217984
Email : info@qinsun-lab.com
ISO 10555 (Seat Belt Assemblies - Test Methods for Abrasion Resistance)
ECE R16 (Uniform Provisions Concerning the Approval of Safety Belts and Restraint Systems)
FMVSS 209 (Federal Motor Vehicle Safety Standard for Seat Belt Assemblies)
Precision Abrasion Testing
High-resolution force sensor (±0.01 N accuracy) captures subtle webbing degradation, critical for ensuring post-crash performance.
Automated Test Cycles
Programmable waveforms simulate decades of real-world usage (e.g., seat belt retraction, emergency locking) in days.
Advanced Material Analytics
AI-powered software predicts wear patterns, tracks fraying, and generates ISO/ASTM-compliant reports automatically.
User-Centric Design
15.6-inch touchscreen interface with multilingual support (English, German, Chinese, Spanish) and one-touch test protocol selection.
Industrial Durability
Corrosion-resistant frame, IP65 enclosure, and anti-vibration feet ensure long-term reliability in demanding labs.
Product Features
Abrasion Resistance: Applies oscillating friction (0–50 N) at angles up to ±45°.
Load Retention: Measures webbing tensile strength after 100.000+ cycles.
Temperature Control: -30°C to +80°C chamber for accelerated aging tests.
High-speed cameras (2.000 FPS) capture webbing fraying and edge wear.
Cloud-compatible software stores 100.000+ test results, generates ECE/FMVSS reports, and supports barcode scanning.
Adjustable clamps accommodate all webbing types (polyester, nylon, Kevlar®).
Accessories Included
Specimen Clamps: Adjustable fixtures for polyester, nylon, and Kevlar® webbing.
Calibration Kit: Force sensor, angular encoder, and NIST-traceable certification.
Safety Gear: Heat-resistant gloves, face shield, and emergency eyewash station.
User Manual & Software: Digital guide (multilingual) + AI analytics platform for fatigue life prediction.
Environmental Chamber: Temperature-controlled enclosure with antifreeze additive.
Automotive OEMs (seat belt manufacturers, safety systems R&D labs)
Regulatory testing agencies (ECE, FMVSS compliance)
Aerospace seating durability testing
Consumer product safety laboratories
| Parameter | Specification |
|---|---|
| Abrasion Force Range | 0–50 N (±0.01 N accuracy) |
| Angular Adjustment | ±45° (±0.01° resolution) |
| Frequency Range | 0.1–15 Hz (adjustable) |
| Temperature Control | -30°C to +80°C (±0.5°C accuracy) |
| Data Acquisition Rate | 150.000 Hz (force/angular channels) |
| Power Supply | 220V/110V AC, 50/60Hz, 2.5kW |
| Dimensions (L×W×H) | 1.3×0.9×1.8 m |
| Weight | 380 kg |
| Operating Environment | 5–40°C, ≤85% RH (non-condensing) |
