Airflow Method Fabric Drying Rate Tester

The Airflow Method Fabric Drying Rate Tester is an automated precision instrument engineered to quantify the drying kinetics of textiles at their maximum absorptive capacity. Designed in strict accordance with the AATCC 200 standard, this equipment evaluates how quickly a fabric can dissipate moisture when exposed to a controlled transverse airflow. By integrating high-speed infrared temperature sensing and precise volumetric water delivery, you can obtain an objective measurement of a material's "quick-dry" performance. This system is essential for quality assurance and R&D, providing fabric designers with the empirical data needed to optimize moisture management in functional textiles.

Applications

The Airflow Method Fabric Drying Rate Tester is an automated testing instrument designed to measure the drying rate of textiles in accordance with the requirements of the American Association of Textile Chemists and Colorists (AATCC) Test Method 200.

Standards

AATCC 200-2017: Drying Rate of Textiles at their Absorbent Capacity: Airflow Method.

GB/T 43822-2024: Textiles — Determination of drying rate at maximum water absorption capacity.

ISO 17617: (Related Reference) Textiles — Determination of moisture drying rate.

Features

1. Incorporates high-precision wind speed sensors, infrared temperature sensors, moisture measurement sensors, high-precision wind speed control devices, and alternating drip-sensing and infrared measurement mechanisms.

2. Combined with software, it automatically completes fabric maximum water absorption measurement, drying time and drying rate testing, along with a series of data analyses. This significantly enhances work efficiency and measurement accuracy while reducing errors and mistakes caused by manual operation.

3. The drying rate tester software transmits data to the host via USB port. Data is displayed and saved in graphical and chart formats for convenient user analysis and printing.

4. Wide adjustable ranges for wind speed (0.2–4.5 m/sec) and drip volume (0.05–4.5 ml).

5. The airflow method tester not only meets the AATCC 200 testing standard but also serves as a valuable tool for fabric designers.

Parameters

Accessories

Main Tester Unit (1 set): The core airflow and sensing assembly.

Analysis Software (1 set): Dedicated program for data acquisition and curve plotting.

Calibrated Drip System: For precise volumetric moisture application.

Sample Pressure Bar (1 pc): Ensures flat and secure specimen positioning.

USB Communication Cable: For high-speed data transfer to the PC.

Industrial Computer (Optional): Pre-configured dedicated workstation for test management.

Test Procedures

Power-Up Preparation: Connect the power supply, start the main unit, and wait for the system self-test to complete.

Parameter Setup: Enter the company name, operator, and test time on the touchscreen. Set parameters such as test pressure and liquid volume.

Sample Placement: Trim the sample and lay it flat on the test platform, ensuring complete coverage.

Test Initiation: Select the test mode and click “Start.” The test head will automatically descend, dispense water upon contacting the sample, and the system will record parameter changes in real time.

Data Export: After the test completes, click “Data Export” to generate a report. Supports USB drive or network transfer.

FAQ

1.What is the purpose of the Airflow Method Fabric Drying Rate Tester?

It measures drying rate and drying time of textiles at maximum water absorption under controlled airflow conditions, providing quantitative moisture-wicking data.

2.Which types of fabrics can be tested?

Sportswear, quick-dry garments, knitted fabrics, bedding, towels, and functional textiles. The system is suitable for a wide range of absorbent fabrics.

3.How is moisture applied to the fabric during testing?

The instrument uses a calibrated drip system with high precision, ensuring reproducible water application (0.05–4.5 ml).

4.How is airflow controlled and measured?

High-precision wind speed sensors monitor and adjust airflow between 0.2 and 4.5 m/s to ensure consistent drying conditions.

5.How are temperature and drying performance recorded?

Infrared sensors measure fabric surface temperature in real time, while software generates curves and charts of drying rate and time for each sample.

6.Can the results be exported for analysis?

Yes, the system supports USB data transmission and automatically generates curves, charts, and printable reports.
