YG401E-6 Quietest/Noiseless Textile Tester Martindale Abrasion and Pilling Tester Price

USAGEyLLTextile Testing Instruments, Testing Equipment Manufacturer
To determine the abrasion and pilling resistance of all kinds of textile structures.yLLTextile Testing Instruments, Testing Equipment Manufacturer
TESTING STANDARDSAbrasion TestsASTM D4966 Standard Test Method for Abrasion Resistance of Textile Fabrics (Martindale Abrasion Tester Method)yLLTextile Testing Instruments, Testing Equipment Manufacturer
ISO 12947-1 Textiles -- Determination of the abrasion resistance of fabrics by the Martindale methodyLLTextile Testing Instruments, Testing Equipment Manufacturer
BS 2543,BS 3424-24,BS 5690,BS 8428,ISO 17704,ISO 5470-2,IWTO 40,Mamp;S P19,Next 18yLLTextile Testing Instruments, Testing Equipment Manufacturer
SFS 4328,SN 198529,TWC 112,Volvo 1024,7122Pilling Tests:ASTM D4970 Standard Test Method for Pilling Resistance and Other Related Surface Changes of Textile Fabrics: Martindale TesteryLLTextile Testing Instruments, Testing Equipment Manufacturer
ISO 12945-2 Textiles -- Determination of fabric propensity to surface fuzzing and to pilling -- Part 2: Modified Martindale methodyLLTextile Testing Instruments, Testing Equipment Manufacturer
Mamp;S P17,Mamp;S P18C,Next TM26,SN 198525,Woolmark TM196yLLTextile Testing Instruments, Testing Equipment Manufacturer
SALIENT FEATURESyLLTextile Testing Instruments, Testing Equipment Manufacturer
1.Specialized Equipment to determine Abrasion and Pilling Resistance of any type of fabrics.yLLTextile Testing Instruments, Testing Equipment Manufacturer
2.Latest model with six stations for specimen testing at a time.yLLTextile Testing Instruments, Testing Equipment Manufacturer
3.Easy operation via the integrated 7quot; full-color digital touchscreen.yLLTextile Testing Instruments, Testing Equipment Manufacturer
4.Independent digital counting of each testing head and total rotation counter.yLLTextile Testing Instruments, Testing Equipment Manufacturer
5.Easy access to the tested specimens (no need to lift or remove the moving plate) and quick replacement of the abradant surface.yLLTextile Testing Instruments, Testing Equipment Manufacturer
6.Emergency stop switch to stop testing, in urgent, without hindering setting.yLLTextile Testing Instruments, Testing Equipment Manufacturer
7.Three types of load 3Kpa, 9Kpa, 12Kpa are available to test samples as per different standards.yLLTextile Testing Instruments, Testing Equipment Manufacturer
8.Supplied with wrench for fixing the sample holder on the front panel of the Instrument and fixing the sample on the holder itself.yLLTextile Testing Instruments, Testing Equipment Manufacturer
9.Complete with all accessories including one stainless Steel marking pen to draw Lissajous figure.yLLTextile Testing Instruments, Testing Equipment Manufacturer
10.All control amp; components strictly adheres to CE Mark specifications for safety.yLLTextile Testing Instruments, Testing Equipment Manufacturer
11.Supplied with calibration amp; inspection Certificates.yLLTextile Testing Instruments, Testing Equipment Manufacturer
TECHNICAL DETAILSyLLTextile Testing Instruments, Testing Equipment Manufacturer
1.Scope:Abrasion:Flat woven,knitted and certain non-woven fabricsyLLTextile Testing Instruments, Testing Equipment Manufacturer
Pilling:Woven and knitted fabricsyLLTextile Testing Instruments, Testing Equipment Manufacturer
2.No. of specimens:up to 6 (for Abrasion or pilling)yLLTextile Testing Instruments, Testing Equipment Manufacturer
3.Exposed area of test specimen:6.45cmsup2;(Abrasion),64.5cmsup2;(Pilling)yLLTextile Testing Instruments, Testing Equipment Manufacturer
4.Working pressure on test specimen:3kpa, 9kpa and 12kpayLLTextile Testing Instruments, Testing Equipment Manufacturer
5.Rotational Speed:47.5 plusmn; 2.5rpm yLLTextile Testing Instruments, Testing Equipment Manufacturer
6.Total stroke of drive units:60.5 plusmn; 0.5mm (Abrasion),24.0 plusmn; 0.5mm (Pilling)yLLTextile Testing Instruments, Testing Equipment Manufacturer
7.Parallelism of top plate to abrading tables:=0.05mmyLLTextile Testing Instruments, Testing Equipment Manufacturer
8.Parallelism of sample holders to abrading tables:=0.05mmyLLTextile Testing Instruments, Testing Equipment Manufacturer
9.Dimensions:885 x 600 x 410 mmyLLTextile Testing Instruments, Testing Equipment Manufacturer
10.Power supply:220V,50Hz or 110V,60HzyLLTextile Testing Instruments, Testing Equipment Manufacturer
11.Weight:150 KgyLLTextile Testing Instruments, Testing Equipment Manufacturer
ACCESSORIES SUPPLIED WITH THE INSTRUMENTyLLTextile Testing Instruments, Testing Equipment Manufacturer
1.Main Unit:01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
2.Top Moving Plate:01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
3.Sample Cutter (Oslash;140mm):01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
4.Sample Cutter (Oslash;38mm):01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
5.Abrading Platform Clamping Rings:06 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
6.Numbered Specimen Holders:06 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
7.Weights (12 kPa) (for Upholstery):06 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
8.Weights (9 kPa) (for Apparel Testing):06 Nos. yLLTextile Testing Instruments, Testing Equipment Manufacturer
9.Loading Pins:06 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
10.S.Steel Balls:03 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
11.Pen to Make Lissajous Figure Abrasion amp; Pilling:01 No. yLLTextile Testing Instruments, Testing Equipment Manufacturer
12.Increasing Load:01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
13.Standard Woven Felt Pad ( 140 mm):12 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
14.Standard Polyurethane Foam ( 38mm):30 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
15.Standard Abradant Fabrics ( 140mm):12 Nos.yLLTextile Testing Instruments, Testing Equipment Manufacturer
16.Pilling Test Accessories:01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
17.This User's Manual:01 No.yLLTextile Testing Instruments, Testing Equipment Manufacturer
18.Inspection amp; Conformance Certificate:01 No. yLLTextile Testing Instruments, Testing Equipment Manufacturer
