In situ multi-channel storage gas production test system

Standard

• UL 1642: Standard for Lithium Batteries
• IEC 62133-2: Secondary Cells and Batteries Containing Alkaline or Non-Acid Electrolytes
• UN 38.3: Recommendations on the Transport of Dangerous Goods – Test Manual
• ASTM G31-72: Standard Practice for Laboratory Immersion Corrosion Testing of Metals
• CE Certification (Conformité Européenne)

Product Advantages

1. Real-Time Gas Composition Analysis
   • Quadrupole Mass Spectrometer: Detects H₂, CO₂, CH₄, and VOCs with 1 ppm sensitivity.
   • FTIR Integration: Simultaneous quantification of gas species and humidity.
2. High-Throughput Safety Testing
   • 16-Channel Parallel Testing: Monitor 16 batteries simultaneously under identical/custom conditions.
   • Auto-Sequence Programming: 100+ preloaded test profiles (overcharge, thermal abuse, etc.).
3. Precision Pressure Control
   • 0-100 bar Dynamic Range: Patented piston-cylinder design with ±0.05% FS accuracy.
   • Burst-Disk Safety System: Dual redundant pressure relief at 120 bar.
4. Thermal Stability
   • -40°C to 200°C Environmental Chamber: Rapid temperature cycling (10°C/min slope).
   • Infrared Pyrometer: Non-contact surface temperature mapping (±0.5°C accuracy).
5. Data Intelligence
   • AI Anomaly Detection: Flags abnormal gas generation patterns in real-time.
   • 3D Visualization: Correlates pressure, temperature, and gas composition in 4D plots.

Product Features

• Non-Destructive Testing (NDT): Optical pressure sensors prevent sample contamination.
• Explosion-Proof Enclosure: 316L stainless steel chamber with 10 mm acrylic viewport.
• Auto-Calibration: NIST-traceable gas mixtures verify sensor accuracy daily.
• Modular Expansion: Add up to 64 channels via daisy-chain configuration.
• Emergency Venting: Mechanical and chemical (CO₂) fire suppression system.

Technical Parameters

Accessories Included

1. Testing Kit:
   • 16x pressure-rated test cells (20 mL – 2,000 mL capacity).
   • Pre-calibrated gas cylinders (H₂/N₂ mix, CO₂/Ar mix).
2. Software Suite:
   • License key for GasAnalyst Pro (Windows/Linux).
   • 6-month free access to cloud-based failure prediction API.
3. Safety Equipment:
   • Explosion-proof gloves (Class 00, 3 pairs).
   • Gas leak detector with audible/visual alarms.
4. Maintenance Kit:
   • Spare O-rings and pressure transducers.
   • Cleaning solution for optical sensors.
5. Documentation:
   • Multilingual quick-start guide (printed + digital).
   • Compliance certificates for UL/IEC/UN standards.
